Orange Bakelite Sheet 3025 - Phenolic Insulation Board
Expected Delivery on - .
Free Shipping & Return
Money back guarantee
Fast & reliable support
Secure payment
Free standard shipping provided, no shipping fee required. Contact customer service for expedited shipping. Return within 30 days, duties & taxes non-refundable.
- 200x300x8mm (1Pcs) - $33.31
- 200x200x8mm (1Pcs) - $30.13
- 400x400x6mm (1Pcs) - $39.94
- 300x400x6mm (1Pcs) - $33.39
- 300x300x6mm (1Pcs) - $32.69
- 200x300x6mm (2Pcs) - $35.88
- 200x200x6mm (2Pcs) - $29.80
- 400x400x5mm (1Pcs) - $36.57
- 300x400x5mm (1Pcs) - $33.57
- 300x300x5mm (1Pcs) - $30.57
- 200x300x5mm (2Pcs) - $48.57
- 200x200x5mm (2Pcs) - $44.12
- 100x200x5mm (2Pcs) - $35.13
- 400x400x30mm (1Pcs) - $200.90
- 300x400x30mm (1Pcs) - $150.24
- 300x300x30mm (1Pcs) - $123.21
- 200x300x30mm (1Pcs) - $75.73
- 200x200x30mm (1Pcs) - $50.40
- 400x400x25mm (1Pcs) - $167.44
- 300x400x25mm (1Pcs) - $124.91
- 300x300x25mm (1Pcs) - $93.97
- 200x300x25mm (1Pcs) - $63.57
- 200x200x25mm (1Pcs) - $42.29
- 400x400x20mm (1Pcs) - $131.57
- 300x400x20mm (1Pcs) - $98.25
- 300x300x20mm (1Pcs) - $74.37
- 200x300x20mm (1Pcs) - $49.46
- 200x200x20mm (1Pcs) - $33.57
- 400x400x15mm (1Pcs) - $98.25
- 300x400x15mm (1Pcs) - $74.37
- 300x300x15mm (1Pcs) - $56.43
- 200x300x15mm (1Pcs) - $37.53
- 200x200x15mm (1Pcs) - $30.07
- 400x400x12mm (1Pcs) - $79.13
- 300x300x12mm (1Pcs) - $44.70
- 200x300x12mm (1Pcs) - $33.39
- 200x200x12mm (1Pcs) - $30.31
- 400x400x10mm (1Pcs) - $66.38
- 300x400x10mm (1Pcs) - $49.46
- 300x300x10mm (1Pcs) - $37.53
- 200x300x10mm (1Pcs) - $25.07
- 200x200x10mm (1Pcs) - $29.13
- 400x400x8mm (1Pcs) - $52.66
- 300x400x8mm (1Pcs) - $39.94
- 300x300x8mm (1Pcs) - $30.39
Orange Bakelite Sheet 3025 - Phenolic Insulation Board
PRODUCT DETAILS
Orange Bakelite Insulation Board - Industrial Grade Phenolic Laminate
Our orange bakelite sheets (3025 grade) are high-performance phenolic cotton cloth laminate boards engineered for demanding electrical and mechanical applications. Made from cotton fabric impregnated with phenolic resin, these boards deliver exceptional electrical insulation, mechanical strength, and heat resistance up to 150°C.
Available in thicknesses from 1mm to 20mm and multiple standard sizes. No minimum order quantity. Can't find your size? We offer custom cutting and CNC machining services to meet your exact specifications.
Key Features
- Superior Electrical Insulation - Dielectric strength suitable for high-voltage applications up to 20kV
- High Temperature Resistance - Continuous operating temperature up to 130°C, peak 150°C
- Excellent Mechanical Strength - Tensile strength ≥120MPa with superior impact resistance
- Easy to Machine - Excellent machinability for CNC drilling, cutting, milling, and turning
Technical Specifications
| Material Grade | 3025 Phenolic Cotton Cloth Laminate |
| Base Material | Cotton Fabric + Phenolic Resin |
| Color | Orange (Red-Orange) |
| Thickness Range | 1mm - 20mm |
| Temperature Resistance | Continuous: 130°C | Peak: 150°C |
| Dielectric Strength | ≥16 kV/mm |
| Tensile Strength | ≥120 MPa |
| Thermal Rating | E Class (120°C) |
Common Applications
Electrical & Electronic Equipment
- Transformer Components - Insulation boards, slot wedges, spacers for transformer assemblies
- Switchgear & Distribution Panels - Insulating backing plates, terminal boards, barrier panels
- Motor & Generator Parts - Insulation components, slot liners, phase insulation
- PCB Manufacturing - Drilling backing boards, test fixtures, jig plates
- High Voltage Equipment - Insulating supports, bushings, terminal blocks (rated up to 20kV)
Industrial & Mechanical Applications
- Precision Machinery - Bearing pads, guide wheels, structural supports
- Manufacturing Fixtures - Mold plates, jig boards, fixture components
- Gears & Rollers - Low-friction mechanical components requiring electrical insulation
- Thermal Barriers - Heat shields, insulation panels for high-temperature equipment
Why Choose Orange Bakelite (3025) Over Black (3026)?
Orange bakelite 3025 uses cotton cloth reinforcement, providing superior mechanical strength compared to paper-based black bakelite (3026). Benefits include:
- Better impact resistance and toughness
- Improved dimensional stability under load
- Enhanced machinability with cleaner cuts
- Superior performance in applications requiring both electrical insulation and mechanical strength
Custom Fabrication Services
Standard sheets not meeting your requirements? We offer comprehensive custom cutting and CNC machining services to fabricate bakelite parts exactly to your specifications - no minimum order quantity required.
✂️ Precision Cut-to-Size
Custom rectangular or square sheets cut to your exact dimensions. Tolerance: ±0.5mm standard.
🔧 CNC Machining
Complex shapes, holes, slots, pockets, and 3D geometries. Tolerances down to ±0.03mm.
⚙️ CNC Milling
Precision milling for flat parts, pockets, contours, and surface finishing.
🎯 CNC Turning
Round parts, bushings, spacers, and cylindrical components machined from bakelite stock.
How to Order Custom Parts
- Send Your Specifications - Upload CAD drawings (PDF, DXF, DWG, STEP) or provide dimensions and quantity
- Receive Quote - Get detailed quotation within 24 hours including pricing and lead time
- Review & Approve - Our engineers will review for manufacturability and suggest optimizations if needed
- Production & Delivery - Standard custom orders ship within 3-5 business days
📐 No minimum order quantity - Order 1 piece for prototyping or 1000+ for production runs
Explore More Phenolic Laminates
Looking for other phenolic laminate options? Browse our complete collection of Bakelite & Garolite materials including:
- Black Bakelite (3026) - Paper-based phenolic laminate for superior electrical insulation
- Garolite G10/FR4 - Fiberglass reinforced epoxy laminate for high-strength applications
- Canvas Phenolic (CE) - Heavy-duty laminate for mechanical and structural parts
- Linen Phenolic (LE) - Fine-textured laminate for precision components
Browse All Phenolic Laminates →
Frequently Asked Questions
What's the difference between orange bakelite 3025 and black bakelite 3026?
Orange bakelite (3025 grade) uses cotton cloth reinforcement, providing superior mechanical strength, impact resistance, and machinability. Black bakelite (3026 grade) uses paper reinforcement, offering better electrical insulation properties. For applications requiring balanced electrical and mechanical performance, orange 3025 is preferred.
Can orange bakelite be used in transformer oil?
Yes, 3025 phenolic cotton cloth laminate is suitable for use in transformer oil environments. It maintains its mechanical and electrical properties when immersed in mineral oil.
What's the minimum order quantity?
We have no minimum order quantity for both standard sheets and custom-cut parts. Order 1 piece for testing or prototyping, or bulk quantities for production.
How quickly can you deliver custom-cut parts?
Standard sheets ship within 1-2 business days. Custom cut-to-size orders typically ship within 3-5 business days. Complex CNC machined parts ship within 5-7 business days depending on complexity.
Can bakelite be machined with standard tools?
Yes, bakelite machines well with carbide or high-speed steel cutting tools. It can be drilled, milled, turned, and cut without special equipment. For best results, use sharp tools and moderate cutting speeds to prevent overheating.
Do you ship internationally?
Yes, we ship worldwide. Standard international shipping (15-25 business days) is free. Expedited shipping (3-6 business days) is available at additional cost.
Why Choose BeePlastic?
- ✓ No Minimum Order Quantity - Order exactly what you need, from 1 piece to bulk quantities
- ✓ Fast Turnaround - Standard sheets ship within 1-2 days, custom orders within 3-5 days
- ✓ Expert Engineering Support - Free design consultation and manufacturability reviews
- ✓ Precision Manufacturing - CNC machining tolerances down to ±0.03mm
- ✓ Competitive Pricing - Factory-direct pricing with volume discounts available
- ✓ Quality Guaranteed - Consistent material quality with full traceability
- ✓ Global Shipping - Free standard international shipping, expedited options available
Questions or Need Technical Support?
Our engineering team is here to help. Contact us for material selection advice, design consultation, or custom project inquiries.
