Polyvinylidene Fluoride (PVDF), also known by trade names like Kynar®, Hylar®, and Solef®, represents the pinnacle of high-performance thermoplastic engineering. This exceptional fluoropolymer combines outstanding chemical resistance with superior mechanical properties, making it the material of choice for the most demanding industrial applications.

Whether you need custom machined PVDF components, precision-fabricated parts, or raw PVDF materials for your own processing, BeePlastic delivers comprehensive solutions. Our expertise in PVDF machining and fabrication ensures your components meet exact specifications while maintaining the material's inherent properties.

• ✓ Maximum service temperature: 150°C (302°F) continuous
• ✓ Exceptional chemical resistance to acids, bases, and solvents
• ✓ Outstanding UV and weather resistance for outdoor applications
• ✓ High purity for semiconductor and pharmaceutical use

Precision-machined PVDF components with tight tolerances

Mechanical Properties

Thermal & Physical Properties

🧪 Chemical Processing Industry

PVDF's exceptional resistance to acids, bases, and organic solvents makes it ideal for chemical handling equipment. Custom machined PVDF components for pumps, valves, tanks, and piping systems.

• • Chemical pump components & diaphragms
• • Tank linings and vessel internals
• • Valve seats and seals
• • Corrosion-resistant fittings

💻 Semiconductor Manufacturing

Ultra-pure PVDF materials for wet bench equipment and chemical delivery systems. Precision machining ensures contamination-free processing in cleanroom environments.

• • Wet bench components
• • Chemical delivery manifolds
• • Wafer carriers and cassettes
• • Ultra-pure fluid handling parts

⚡ Oil & Gas Industry

PVDF withstands harsh downhole conditions, aggressive chemicals, and high temperatures. Custom components for exploration, production, and refining operations.

• • Downhole tool components
• • Chemical injection parts
• • Pipeline linings
• • Instrumentation housings

💊 Pharmaceutical & Biotech

High-purity PVDF for pharmaceutical processing equipment. Non-contaminating, chemically inert components for drug manufacturing and biotechnology applications.

• • Process vessel components
• • Filtration system parts
• • Laboratory equipment
• • Clean-in-place (CIP) components

💧 Water Treatment

PVDF's resistance to chlorine and UV degradation ensures long service life in water treatment systems. Custom parts for filtration, membrane systems, and chemical dosing.

• • Membrane support structures
• • Chemical feed components
• • Filter housings and cartridges
• • UV-resistant outdoor equipment

✈️ Aerospace & Defense

Lightweight PVDF components with excellent flame resistance and low smoke generation. Precision machined parts meeting stringent aerospace specifications.

• • Wire and cable insulation
• • Fuel system components
• • Interior trim parts
• • Sensor housings

Precision Manufacturing

Advanced CNC equipment calibrated for PVDF machining. Achieve ±0.03mm tolerance consistently across all your custom fluoropolymer components.

Fast Turnaround

From rapid prototyping to production runs, we deliver PVDF parts when you need them. Express service available for urgent requirements.

Material Expertise

Deep understanding of PVDF properties and processing requirements. We optimize machining parameters to maintain material integrity.

Engineering Support

Collaborate with our technical team to optimize your PVDF component design for manufacturability and performance.

Quality Assurance

Rigorous inspection protocols ensure every PVDF part meets specifications. Full dimensional reports and material traceability available.

Global Delivery

Worldwide shipping with secure packaging. Your custom PVDF components delivered safely to any destination.

PVDF Sheets

Thickness: 1mm to 100mm
Sizes: Up to 1220mm x 2440mm
Natural white, black available

PVDF Rods

Diameter: 6mm to 300mm
Length: Up to 3000mm
Solid and hollow available

PVDF Tubes & Films

Custom dimensions available
Thin films from 0.05mm
Special grades on request

Semiconductor Wet Bench Components

Challenge: A semiconductor manufacturer needed ultra-pure PVDF manifolds with complex internal channels for chemical delivery, requiring exceptional dimensional accuracy and surface finish.

Solution: Precision 5-axis CNC machining with specialized tooling achieved ±0.03mm tolerance on all critical dimensions. Custom fixturing ensured perfect alignment of intersecting channels.

Result: Zero contamination issues after 12 months of continuous operation. Client expanded order to include additional PVDF components for new production lines.

Chemical Processing Valve Components

Challenge: Custom PVDF valve seats and seals for highly corrosive acid service. Required perfect sealing surfaces and dimensional stability under thermal cycling.

Solution: Combined CNC machining with specialized surface finishing techniques. Implemented rigorous quality control with 100% dimensional inspection.

Result: Extended valve service life by 300%. Customer reported significant reduction in maintenance costs and unplanned downtime.

What makes PVDF superior to other fluoropolymers like PTFE?

While PTFE offers superior chemical resistance, PVDF provides better mechanical strength, stiffness, and dimensional stability. PVDF is also easier to machine and weld, making it more cost-effective for many applications. Its piezoelectric properties and flame resistance make it unique among fluoropolymers.

Can PVDF be used in outdoor applications?

Absolutely. PVDF exhibits exceptional UV resistance and weatherability, maintaining its properties even after decades of outdoor exposure. It's widely used in architectural applications, outdoor chemical storage, and solar panel components. The material resists degradation from sunlight, rain, and temperature cycling.

What tolerances can be achieved when machining PVDF?

Our advanced CNC equipment achieves tolerances of ±0.03mm (±0.0012") for PVDF components. Tighter tolerances are possible for specific features with appropriate tooling and fixturing. The key is using sharp tooling, proper speeds/feeds, and adequate cooling to prevent thermal expansion during machining.

Is PVDF suitable for high-purity applications?

Yes, PVDF is extensively used in semiconductor, pharmaceutical, and ultrapure water applications. The material exhibits extremely low extractables and particle generation. Natural PVDF contains no additives or stabilizers that could contaminate sensitive processes. Special high-purity grades are available for the most demanding applications.

Can PVDF components be welded or bonded?

PVDF can be effectively welded using hot air, extrusion, or butt fusion welding techniques. This allows fabrication of complex assemblies, tanks, and piping systems. While adhesive bonding is challenging due to PVDF's low surface energy, surface treatments can improve bondability. We offer complete PVDF welding and assembly services.
