Transform Your Design Into Precision Reality
Custom plastic machining with Swiss precision
Our Comprehensive CNC Plastic Machining Capabilities
Precision CNC Plastic Machining Services
Custom Plastic Parts & Components Manufacturing
Transform your designs into high-precision plastic components with ±0.03mm (±0.0012") accuracy. 15+ years expertise in CNC milling, turning & routing of engineering plastics including PEEK, POM, PTFE, Nylon, PC, ABS and more. No MOQ • 24-Hour Quote • Free DFM Analysis • Global Shipping
Advanced CNC Plastic Machining Capabilities
CNC Milling Services
3, 4 & 5-axis CNC milling for complex plastic components. Precision machining of engineering thermoplastics and composites with specialized diamond-coated and carbide tooling.
- 3D contouring & complex surfaces
- Pockets, cavities & undercuts
- Holes, slots & threaded features
- Tight tolerances: ±0.03mm standard
CNC Turning (Lathing)
High-precision CNC turning of plastic rods into cylindrical components. Expert machining of bushings, spacers, insulators and custom plastic shafts.
- OD/ID diameter control
- Threading (internal/external)
- Grooving & parting operations
- Superior surface finishes
5-Axis CNC Machining
Advanced multi-axis machining for the most complex geometries. Single-setup production of intricate aerospace, medical and robotics components.
- Complex undercuts & angles
- Reduced setup time
- Enhanced accuracy
- Aerospace-grade precision
CNC Routing Services
High-speed CNC routing for plastic sheets and panels. Perfect for large format parts, custom profiles and production cutting.
- Large format capabilities
- Profile cutting & shaping
- Edge finishing & polishing
- Panel optimization
Engineering Plastics & High-Performance Materials
Expert CNC machining of 50+ plastic materials including thermoplastics, engineering polymers and composites. Each material is optimized for specific properties: chemical resistance, temperature stability, low friction, or high strength.
High-Performance Engineering Plastics
Engineering Thermoplastics
General Purpose Plastics
Precision CNC Machining Process Excellence
Advanced Milling Technologies
Our multi-axis CNC milling centers deliver unparalleled precision for complex plastic components. Utilizing high-speed spindles up to 40,000 RPM and specialized diamond-coated tooling for composites, we achieve exceptional surface finishes while maintaining tight tolerances of ±0.03mm (±0.0012").
Key Milling Capabilities:
- Heat Management: Advanced cooling systems and optimized cutting parameters prevent thermal deformation in thermoplastics like PC, PMMA, and ABS
- Chip Evacuation: High-pressure air blast and vacuum systems ensure clean surfaces and prevent chip re-welding
- Tool Selection: Extensive library of single-flute, O-flute, and diamond-coated end mills for different plastic types
- Surface Quality: Ra 0.8-1.6 μm standard, with capability for Ra 0.4 μm on critical surfaces
Materials Expertise
Specialized parameters for PEEK, POM, Nylon, PC, PTFE, and 40+ other engineering plastics
Complex Geometries
3D contouring, undercuts, deep pockets, and intricate features in single setup
High-precision 5-axis CNC milling of complex plastic components with tolerances up to ±0.03mm
From CAD design to finished prototype in 2-3 days for urgent development projects
Rapid Prototyping Excellence
Transform your concepts into physical prototypes with unprecedented speed and precision. Our rapid CNC prototyping services accelerate product development cycles, allowing you to validate designs, test functionality, and iterate quickly using production-grade materials.
Prototyping Advantages:
- 24-Hour Quotes: Upload CAD files and receive detailed quotes within one business day
- Free DFM Analysis: Our engineers review designs for manufacturability and cost optimization
- Material Matching: Test with actual production plastics, not prototype-only materials
- Design Iterations: Quick modifications without expensive tooling changes
- Functional Testing: Parts suitable for real-world testing and validation
Fast Track Service: Critical prototypes can be completed in 48-72 hours. Perfect for design reviews, investor presentations, and urgent product launches.
Precision Turning Capabilities
Expert CNC turning transforms plastic rod stock into high-precision cylindrical components with exceptional concentricity and surface finish. Our advanced lathe technology, combined with specialized tooling and extensive material knowledge, produces parts that meet the most demanding specifications for fit, function, and performance.
Turning Specializations:
Bushings & Bearings
Low-friction POM (Delrin), Nylon, and UHMW-PE components with ID/OD tolerances ±0.025mm
Electrical Insulators
High-voltage FR-4, G-10, and phenolic spacers with precise length control
Sealing Components
PTFE and PEEK valve seats, backup rings with mirror finish surfaces
Drive Components
Custom plastic shafts, rollers, and pulleys with keyways and set screw flats
Technical Capabilities:
- Diameter range: 3mm to 300mm
- Length capacity: Up to 1000mm
- Concentricity: 0.05mm TIR standard
- Surface finish: Ra 0.8 μm achievable
- Threading: Metric, UNC, UNF, ACME
High-precision CNC turned components including bushings, spacers, and custom shafts
Industry Applications & Custom Solutions
Medical Devices
Biocompatible PEEK implants, surgical instruments, diagnostic equipment housings, fluid handling components
Aerospace & Defense
Lightweight structural components, insulation parts, cabin interior fittings, radar transparent radomes
Automotive
Under-hood components, interior trim parts, lighting assemblies, EV battery components
Electronics
PCB insulators, semiconductor handling, electronic enclosures, connector housings
Industrial Equipment
Machine guards, conveyor components, pump parts, wear-resistant guides
Robotics
End effectors, grippers, structural frames, precision gears and pulleys
Advanced 5-Axis CNC Machining & Finishing Services
5-axis simultaneous machining for aerospace and medical grade components
5-Axis Simultaneous Machining
Our 5-axis CNC technology represents the pinnacle of plastic machining capability. By enabling simultaneous movement across five axes, we can approach workpieces from virtually any angle, creating complex geometries that would be impossible or require multiple setups on conventional machines.
Complex Geometries
- Deep cavities with undercuts
- Compound angle features
- Helical grooves and channels
- Turbine blade profiles
Single Setup Benefits
- Eliminates repositioning errors
- Reduces total machining time
- Improves part accuracy
- Enables tighter tolerances
Industry Applications:
Aerospace: Lightweight structural brackets, ducting components, and interior cabin parts requiring complex angles and weight-optimized designs.
Medical: Surgical instrument handles, implant trials, and diagnostic device components with ergonomic curves and precise mating surfaces.
Robotics: End effectors, gripper jaws, and articulated joint components requiring compound angles and integrated mounting features.
Premium Surface Finishing Services
The perfect surface finish can make the difference between a good part and an exceptional one. Our comprehensive finishing services go beyond standard deburring to provide aesthetic appeal, functional improvements, and enhanced performance characteristics tailored to your application.
Available Finishing Options:
Vapor Polishing (For PC & Acrylic)
Achieves optical clarity and glass-like transparency. Perfect for lenses, sight glasses, and display windows. Surface roughness reduced to Ra 0.05-0.1 μm.
Bead Blasting
Creates uniform matte texture for improved grip and reduced glare. Available in various media grades for different surface textures from fine satin to coarse matte.
Mechanical Polishing
Progressive sanding and buffing for high gloss finish on engineering plastics. Ideal for aesthetic components and parts requiring low friction surfaces.
Laser Marking & Engraving
Permanent part identification, serialization, logos, and instructional markings. High contrast marking on most plastic materials without surface damage.
Complete Manufacturing Solutions Beyond CNC
Assembly & Hardware
Complete sub-assembly services including threaded insert installation, press-fit components, and multi-part assembly. Simplify your supply chain with turnkey solutions.
Learn More →Laser Cutting & Engraving
Precision laser cutting for intricate 2D profiles and patterns. Perfect for panels, gaskets, and decorative elements with exceptional edge quality.
Explore Service →Cut-to-Size Services
Custom cutting of plastic sheets, rods, and tubes to your exact specifications. Save time and reduce waste with precision-cut materials.
Get Quote →Plastic Welding
Expert plastic welding for tanks, fabrications, and repairs. Hot gas, extrusion, and ultrasonic welding capabilities for permanent joints.
View Details →Thermoforming & Bending
Heat bending and vacuum forming for complex 3D shapes. Ideal for guards, covers, and custom enclosures from thermoplastic sheets.
Discover More →Injection Molding
Cost-effective production for higher volumes. From prototype tooling to production molds, we handle complete injection molding projects.
Learn More →Specialized High-Performance Plastic Solutions
High-performance PEEK components for extreme temperature applications up to 260°C
PEEK & High-Temperature Engineering Plastics
When standard plastics fail, high-performance polymers excel. Our expertise in machining PEEK, PEI (Ultem), PAI (Torlon), PPS, and other advanced thermoplastics enables us to deliver components that withstand extreme temperatures, aggressive chemicals, and demanding mechanical loads where traditional materials cannot survive.
Material Performance Comparison:
| Material | Max Temp | Key Properties |
|---|---|---|
| PEEK | 260°C | Chemical resistance, biocompatible |
| PEI (Ultem) | 170°C | High strength, flame retardant |
| PAI (Torlon) | 275°C | Extreme wear resistance, dimensional stability |
| PI (Polyimide) | 300°C | Ultra-high temp, low outgassing |
Critical Applications
- Aerospace engine components
- Medical implants & instruments
- Semiconductor equipment
- Oil & gas downhole tools
Processing Excellence
- Specialized carbide tooling
- Controlled environment machining
- Stress-relief protocols
- 100% dimensional inspection
Optical & Transparent Components
Creating truly transparent plastic components requires expertise beyond standard machining. Our specialized processes for polycarbonate, acrylic (PMMA), and PETG combine precision cutting with advanced polishing techniques to achieve optical clarity rivaling glass.
Optical Clarity Process:
Precision Machining
Single-point diamond turning or specialized tooling for minimal surface stress
Progressive Sanding
Multi-stage wet sanding from 400 to 3000 grit for surface preparation
Vapor/Flame Polishing
Chemical vapor or controlled flame treatment for glass-like transparency
Quality Inspection
Optical clarity verification and surface quality measurement
Typical Applications:
Machine safety guards • Medical device lenses • Display windows • Light guides and pipes • Sight glasses • Fluidic devices • Protective covers • Optical prototypes
Crystal-clear polycarbonate housing achieved through precision machining and vapor polishing
Engineering Support & Technical Excellence
Free DFM Analysis
Our engineering team reviews every design for manufacturability. We identify potential issues, suggest optimizations, and help reduce costs while maintaining quality. Get expert feedback before production begins.
Precision Tolerances
Standard tolerance of ±0.03mm (±0.0012") with capability for even tighter tolerances on critical features. Our quality control ensures every part meets your exact specifications.
Material Selection Guide
Not sure which plastic is best for your application? Our experts help you select the optimal material based on mechanical requirements, environmental conditions, and budget constraints.
Frequently Asked Questions About CNC Plastic Machining
What is your minimum order quantity (MOQ)?
We have NO minimum order quantity. Whether you need a single prototype or thousands of production parts, we're equipped to handle orders of any size. This flexibility makes us ideal for R&D projects, custom replacements, and production runs.
What tolerances can you achieve with plastic CNC machining?
Our standard machining tolerance is ±0.03mm (±0.0012") for most plastics. For stable engineering plastics like PEEK, POM, and G-10, we can achieve even tighter tolerances based on part geometry. Critical dimensions should be clearly specified on your technical drawings.
Which file formats do you accept?
We prefer 3D CAD files in STEP (.stp, .step) or IGS (.igs, .iges) format for the most accurate quotes. We also accept 2D drawings in DWG, DXF, or PDF format. Our engineering team can work with you if you need assistance with file preparation.
What is your typical lead time?
Standard lead times are 5-7 business days for most CNC machined plastic parts. Simple parts or urgent prototypes can often be completed in 2-3 days. Complex multi-axis parts or large production runs may require additional time. Rush service is available for critical deadlines.
Do you offer free shipping?
Yes! We offer free standard shipping to many countries and regions worldwide. Express shipping is available at additional cost for urgent deliveries. Contact us for specific shipping information to your location.
Can you machine custom plastic materials I provide?
Yes, we can machine customer-supplied materials. However, we recommend using our stock materials when possible to ensure consistent quality and material properties. If you have special material requirements, our team can source specialty plastics for your project.
Quick Material Selection Guide
Choose the right plastic for your CNC machining project based on your application requirements
For High Temperature (>200°C)
Best choices for heat resistance:
- PEEK: Up to 260°C continuous
- PEI (Ultem): Up to 170°C
- PAI (Torlon): Up to 275°C
- PI (Polyimide): Up to 300°C
For Low Friction / Wear
Ideal for bearings and slides:
- POM (Delrin): Excellent wear resistance
- PTFE: Lowest friction coefficient
- UHMW-PE: Self-lubricating
- Nylon: Good wear, absorbs vibration
For Transparency
Clear plastic options:
- Acrylic (PMMA): Best optical clarity
- Polycarbonate: Impact resistant clear
- PETG: Chemical resistant clear
- PVC: Economical transparent option
For Electrical Insulation
Non-conductive materials:
- FR-4/G-10: Glass-epoxy composite
- Phenolic: High dielectric strength
- PEEK: High temp insulation
- Nylon: Good insulator, cost-effective
For Chemical Resistance
Resistant to acids/solvents:
- PTFE: Inert to most chemicals
- PEEK: Excellent resistance
- PP: Good acid resistance
- HDPE: Resistant to many chemicals
For Cost-Effective Prototypes
Budget-friendly options:
- ABS: Easy to machine, versatile
- PVC: Economical, rigid
- HDPE: Low cost, durable
- Acrylic: Clear option, affordable
Your Journey From Design to Delivery
Submit Design
Upload your CAD files and specifications
DFM Review
Free engineering analysis & optimization
24-Hour Quote
Detailed pricing and lead time
Precision Machining
Expert CNC production begins
Quality Control
100% inspection before shipping
Global Delivery
Fast, secure worldwide shipping
Ready to Start Your CNC Plastic Machining Project?
Join thousands of engineers and designers who trust BeePlastic for precision plastic components. From prototype to production, we deliver quality you can depend on.
Have Questions? Contact Our Expert Team
Email: beeplastic@beeplastic.com
We're here to help you select the right materials and machining solutions for your project
Precision Plastic Parts We've Delivered
From transparent acrylic displays to precision gears, high-temp phenolic components to custom seals
——we machine any plastic, any complexity.
Custom Plastic Fabrication
1pc to 10,000+ | ±0.03mm | No MOQ
General
HDPE
PP
PVC
ABS
Engineering
POM
Nylon
PC
PMMA
High-Performance
PEEK
PEI
PTFE
Composites
FR-4
G10
Flexible
TPU
Silicone
Why Choose BeePlastic?
Get Quote in 24h
Industries: Automotive • Medical • Food • Lab • Semiconductor
Free consultation → beeplastic@beeplastic.com
24H QUOTE DELIVERY
Upload CAD, get quote in 24 hours
NO MOQ REQUIRED
From 1 prototype to high volume
±0.03MM PRECISION
Advanced CNC with full QC inspection
1000+ TONS STOCK
26+ materials ready to ship
